Carbon Floating Ring Seals

Carbon Floating Ring Seal

LPEWDKS

The Carbon Floating Ring Seal is designed to prevent leakage in pumps and rotating equipment by creating a secure seal between the rotating shaft and stationary housing. Engineered for durability and consistent sealing performance, it helps protect equipment, reduce fluid loss, and support efficient operation across various industrial applications. Since 2002, Lineproof Engineering, based in Mumbai, has been providing precision-engineered mechanical shaft seals and reliable sealing components designed to meet the operational needs of modern process industries.

Carbon Floating Ring Seal for Carbon Floating Ring Seals

Face Material

Carbon Graphite.

Metal Parts

SS 316, SS 304, Duplex.

Operating Limits

Shaft Diameter 45 mm to 160 mm
Pressure 1.5 bar (max.)
Temperature −120 °C to 500 °C
Speed 150 m/s

Characteristics

Multi-part seal rings, radially cut
Split housing design
Very small operation gap – low leakage
Dry running
Self-adjusting seal rings
Seal rings bear radial shaft movements
Compensates axial shaft movements
No sealing components mounted on the shaft (no additional shaft vibrations)
Seal rings run contact-free – sliding faces & machine consume no additional power
